Wind turbine blades must be lightweight enough to rotate efficiently, yet stiff and durable enough to withstand millions of load cycles during their service life. As blades become longer, selecting the right structural core material becomes increasingly important.
A core material is placed between composite skins to form a sandwich structure. This construction increases panel stiffness without adding the weight of a solid laminate. In wind turbine blades, structural cores are commonly used in blade shells, shear webs and other sandwich sections where resistance to buckling and shear loading is required.
However, there is no single core material, density or surface treatment suitable for every blade. The correct selection depends on the blade design, location of the core, mechanical requirements, infusion process, resin consumption, operating temperature and production cost.
This guide explains how to choose between PVC foam and PET foam and how density, thickness, surface treatment and kitting influence blade performance and manufacturing efficiency.
Why Wind Turbine Blades Need Core Materials
A wind turbine blade is subjected to complex combinations of bending, shear, compression, fatigue and local pressure throughout its operating life. Making the entire blade from a thick solid fiberglass laminate would add excessive weight and material cost.
A sandwich structure provides a more efficient solution. It normally consists of:
· An outer composite skin;
· A lightweight structural core;
· An inner composite skin.
The skins carry much of the tensile and compressive loading, while the core separates the skins and transfers shear between them. Increasing the distance between the skins can significantly improve bending stiffness without a proportional increase in weight.
Core materials also help:
· Increase local panel stiffness;
· Improve buckling resistance;
· Maintain the aerodynamic shape of the blade;
· Stabilize large shell sections;
· Transfer shear between laminate skins;
· Reduce the amount of solid laminate required;
· Support efficient production of large composite structures.
The core must therefore be evaluated as part of the complete sandwich structure—not as an isolated material.
Where Are Core Materials Used in a Wind Turbine Blade?
Core material requirements vary across the blade because loads, geometry and laminate construction are not uniform.
Blade Shells
The aerodynamic shell forms the external surface of the blade. Large shell areas need sufficient stiffness to maintain their shape and resist local buckling under aerodynamic and operational loads.
Structural foam cores are commonly used in sandwich sections of the shell. Their density, thickness and mechanical performance are selected according to the local structural design.
The core must also conform to the curved mould surface and remain stable during resin infusion and curing.
Shear Webs
Shear webs connect the two sides of the blade and help transfer shear loads while maintaining the separation of the load-carrying spar caps.
Sandwich panels used in shear webs require dependable shear properties, dimensional stability and good bonding with the laminate skins. Core kits must also fit accurately because gaps, poorly fitted joints or excess resin accumulation can affect both weight and structural consistency.
Leading- and Trailing-Edge Areas
Core materials may be used in selected leading- and trailing-edge regions to stabilize the shell and improve local stiffness.
These areas can involve tight curvature, narrow sections and complex transitions. Core flexibility, thermoformability, scoring pattern and dimensional accuracy can therefore be as important as the nominal mechanical properties.
Root and High-Load Transitions
The blade root contains thick laminates, inserts, adhesive joints and load-transfer features. A single lightweight foam grade is not automatically suitable throughout this area.
Higher-density core materials or alternative structural solutions may be required around localized loads, connections and transitions. The final specification must be based on the blade designer’s structural calculations.
PVC Foam or PET Foam?
PVC and PET are both used as structural foam cores, but they have different performance and processing characteristics. Selection should be based on the requirements of each blade section rather than on price alone.
PVC Foam Core
Cross-linked PVC is a closed-cell structural foam with a strong balance of low weight, mechanical performance and processing reliability.
Typical advantages include:
· Good shear strength and stiffness relative to density;
· Good fatigue resistance;
· Low water absorption;
· Good dimensional stability;
· Compatibility with common composite processing methods;
· Availability in different densities and surface treatments;
· Reliable performance in demanding sandwich structures.
PVC foam can be considered where mechanical efficiency, fatigue performance and low weight are important. It may also be preferred in structurally demanding areas when the selected grade provides the required shear and compression properties.
However, PVC is normally more expensive than standard PET foam. Material choice must therefore consider whether its performance advantages are necessary in the specific blade location.
PET Foam Core
PET is a thermoplastic structural foam widely used in wind turbine blade sandwich construction. It provides a practical balance of mechanical performance, processing capability, cost and sustainability.
Typical advantages include:
· Competitive material cost;
· Good compression and shear performance;
· Good dimensional stability;
· Thermoformability;
· Availability in a wide range of densities;
· Compatibility with vacuum infusion processes;
· Recyclability as a thermoplastic material;
· Availability of grades made with recycled PET content.
PET is especially attractive for large-volume blade production where cost efficiency, consistent supply and sustainability are important.
However, PET grades differ significantly in cell structure, mechanical properties, temperature resistance and resin uptake. The word “PET” alone is not a sufficient specification. The selected grade must be verified against the structural and processing requirements of the blade.
PVC Foam vs PET Foam: Practical Comparison
Selection Factor | PVC Foam | PET Foam |
Material type | Cross-linked thermoset foam | Thermoplastic foam |
Structural efficiency | Strong performance-to-weight balance | Good performance with competitive cost |
Fatigue performance | Generally a key advantage of suitable PVC grades | Must be evaluated by grade and application |
Processing | Suitable for common composite processes | Suitable for infusion and thermoforming |
Thermoformability | Depends on grade and temperature | Generally good |
Resin uptake | Influenced by cell structure and surface treatment | Influenced strongly by grade and processing |
Sustainability | Long service life and lightweight construction | Recyclable; recycled-content grades are available |
Cost | Generally higher | Generally more cost-effective |
Best use | Performance-sensitive sandwich areas | Large-volume, cost-optimized sandwich structures |
This table is a general guide only. Final comparisons must use actual technical data at the selected density and test conditions.
Do Not Select Core Material by Turbine Rating Alone
It can be tempting to say that one material is suitable below a certain turbine capacity and another should be used above it. This is too simplistic.
A turbine’s rated power does not fully describe the structural requirements of its blades. Selection is also affected by:
· Blade length;
· Onshore or offshore installation;
· Rotor speed;
· Aerodynamic design;
· Number and position of shear webs;
· Spar-cap design;
· Shell geometry;
· Target blade weight;
· Design life;
· Safety factors;
· Infusion and curing process.
Two blades with similar power ratings may therefore use different core materials or different combinations of densities.
The blade drawing, laminate schedule and engineering specification should always take priority over a general rule based on megawatt rating.
How to Choose the Correct Foam Density
Foam density affects weight, shear strength, compression performance and cost. A higher density usually provides greater mechanical properties, but it also increases blade weight and material cost.
The objective is not to select the highest density. It is to use the lowest density that safely satisfies the structural and processing requirements of each location.
Consider the following factors:
Shear Loading
The core transfers shear between the laminate skins. Areas exposed to higher shear loads require sufficient shear strength and modulus.
Both static properties and long-term fatigue behavior may be relevant.
Compression and Local Pressure
The core must resist compression during manufacturing and service. Local pressure can occur around tooling features, vacuum consumables, joints and loaded areas.
A core with inadequate compression performance may deform during infusion, curing or operation.
Buckling Resistance
Core thickness and shear stiffness contribute to the buckling resistance of the sandwich panel. Density should therefore be considered together with thickness and skin design.
Weight Target
Using an unnecessarily high density across a large blade area can add substantial weight. Local optimization is usually better than applying one grade to the entire blade.
Processing Conditions
The foam must tolerate vacuum pressure, resin exotherm and curing temperature without unacceptable distortion or property loss.
As a result, one blade may use multiple densities. Lower-density foam can be used in less demanding areas, while higher-density inserts or transition pieces are used where loads are concentrated.
Core Thickness Is as Important as Density
Increasing core thickness can greatly improve sandwich panel stiffness, but thicker material is not automatically better.
The correct thickness depends on:
· Required panel stiffness;
· Local buckling resistance;
· Blade geometry;
· Skin laminate thickness;
· Shear stress in the core;
· Weight limitations;
· Available mould space;
· Manufacturing tolerances.
Thickness transitions should be gradual and accurately machined. Poorly designed steps can create resin-rich areas, stress concentrations or difficulties during lay-up.
The blade designer should specify the final thickness distribution. The core supplier can then manufacture sheets or kits with the required tapers, bevels and transitions.
Surface Treatments for Vacuum Infusion
Wind turbine blades are commonly manufactured by vacuum-assisted resin infusion. Core surface treatment has a direct effect on resin flow, air removal, conformity and resin consumption.
Perforated Foam
Perforations allow air and resin to move through the thickness of the core. Hole diameter and spacing should be selected for the actual infusion strategy.
Too few holes may restrict air removal. Too many or excessively large holes can increase resin consumption and blade weight.
Grooved Foam
Surface grooves create resin-flow channels. Groove direction, spacing and depth influence the speed and uniformity of infusion.
A more aggressive groove pattern can improve flow but may also hold more resin. The fastest infusion pattern is therefore not always the lowest-cost or lowest-weight solution.
Scored and Scrimmed Foam
Rigid foam sheets can be cut into blocks attached to a supporting scrim. This allows the core to follow curved blade moulds more easily.
The dimensions of the blocks, width of the cuts and type of scrim affect conformity and resin uptake. Wide gaps between blocks may become resin-rich after infusion.
Thermoformed Core
PET foam can be thermoformed to match curved blade surfaces. Preformed core may reduce gaps and improve repeatability, but the forming process must be controlled to avoid unacceptable changes in thickness or local properties.
Resin Uptake Matters
Core material cost is only one part of the finished blade cost. Resin absorbed into holes, grooves, cuts, open cells and gaps adds weight and expense.
For a large wind turbine blade, even a small increase in resin uptake per square meter can become significant over the total core area.
Resin uptake is influenced by:
· Foam cell structure;
· Core density;
· Surface porosity;
· Hole diameter and spacing;
· Groove width and depth;
· Scoring pattern;
· Gaps between kit pieces;
· Scrim construction;
· Resin viscosity;
· Vacuum level;
· Infusion temperature.
The selected core configuration should provide sufficient resin flow without creating unnecessary resin channels. Trial panels are useful for comparing infusion time, wet-out, resin consumption and finished panel quality.
Temperature and Dimensional Stability
The core must remain stable throughout storage, lay-up, infusion and curing.
Important temperature-related factors include:
· Maximum mould temperature;
· Resin exotherm;
· Cure duration;
· Post-curing requirements;
· Temperature distribution across thick laminate areas;
· Core softening or distortion;
· Dimensional recovery after cooling.
The temperature stated on a technical data sheet should not be used without understanding how it was defined. Maximum short-term temperature, continuous service temperature and heat distortion temperature are not interchangeable.
Customers should provide the complete cure cycle when selecting a foam grade.
Fatigue Performance
Wind turbine blades experience repeated cyclic loading. A material that passes a short-term static test may not necessarily provide the required long-term fatigue performance.
When fatigue is a design driver, evaluation may include:
· Shear fatigue behavior;
· Compression fatigue;
· Skin-to-core bond durability;
· Property retention after environmental exposure;
· Performance of joints and transitions;
· Variability between production batches.
The core should be qualified as part of the complete sandwich system using the intended skins, resin, adhesive and manufacturing process.
Dimensional Accuracy and Core Kitting
For large blades, core materials are frequently supplied as CNC-machined kits rather than standard rectangular sheets.
A well-designed core kit can provide:
· Accurate fit inside the mould;
· Correct thickness transitions;
· Reduced manual trimming;
· Faster lay-up;
· Consistent gaps between pieces;
· Lower risk of installation errors;
· Better production repeatability;
· Identification of each kit part.
Typical machining options include:
· CNC cutting;
· Beveling;
· Tapering;
· Grooving;
· Perforation;
· Scoring;
· Scrim application;
· Thermoforming;
· Part marking;
· Kit sequencing and packaging.
Material properties alone do not determine the total value of a core system. Machining accuracy, kit design, packaging and delivery reliability can have a major influence on blade production efficiency.
A Practical Core Material Selection Process
A structured selection process helps avoid choosing material based only on density or price.
Step 1: Identify the Blade Location
Determine whether the core is for a shell panel, shear web, leading edge, trailing edge or a localized transition.
Step 2: Define Structural Requirements
Confirm the required shear strength, shear modulus, compression properties, fatigue performance, thickness and allowable weight.
Step 3: Define Processing Conditions
Provide the resin system, infusion method, vacuum level, cure temperature, cure duration and expected exotherm.
Step 4: Compare PVC and PET Grades
Compare properties at equivalent densities and under comparable test conditions. Do not compare only product-family descriptions.
Step 5: Select the Surface Treatment
Choose perforations, grooves, scoring or thermoforming based on geometry and resin-flow requirements.
Step 6: Evaluate Resin Consumption
Measure the influence of the selected surface treatment and joints on finished panel weight.
Step 7: Confirm Kit Requirements
Provide drawings, tolerances, part identification, packaging sequence and expected annual volume.
Step 8: Validate the Complete Sandwich System
Manufacture representative trial panels and test the complete laminate before final approval.
Information to Provide to Your Core Material Supplier
For an accurate recommendation, blade manufacturers should provide:
· Core application area;
· Required material type;
· Target density;
· Core thickness;
· Sheet or kit dimensions;
· Mechanical property requirements;
· Resin system;
· Infusion method;
· Cure cycle;
· Surface treatment;
· Required tolerances;
· Estimated annual quantity;
· Testing and documentation requirements.
Where the blade design is confidential, the customer can provide the minimum relevant processing and performance requirements without sharing the complete structural design.
Final Recommendation
PVC and PET foam can both provide effective structural core solutions for wind turbine blades, but they should not be treated as interchangeable materials.
PVC foam is often considered where high structural efficiency, fatigue resistance and low weight are especially important. PET foam offers a strong combination of mechanical performance, cost efficiency, thermoformability and sustainability for high-volume blade production.
The final choice should be based on the specific blade location, structural calculations, density, thickness, processing temperature, resin uptake and surface treatment. In many cases, the best blade design may use different core grades in different areas rather than relying on one material throughout.
